Mode Data
This area will contain information that relates to the currently selected Display Mode.
Settings Button
The Settings Button will open a Settings area which
contains menus for Display Mode Settings,
General Settings, Serial Port Settings, Diagnostic
Settings, Date & Time Settings and CAN Bus
Settings.
The Display Mode settings shown on the Settings
screen depend on which mode has been selected. You
can find information about the settings for each mode in
the specific mode areas.
Screenshot Button
By pressing the Screenshot Button you can save a full
image of what is currently shown on the screen. This
screenshot will be saved to the inserted SD card as a
1.5 MB bitmap image, orientated at 90° to the original
screen image and with the prefix 'screenshot'.
The LEDs will illuminate
right to display the progress of writing to the SD card.
Each LED represents 25% of the progress of the save.
When the screen capture is complete, VBOX Touch
will emit an audible confirmation notification. If the
screenshot could not be saved, for example, no SD card
is inserted or the card is full, the SD Card Icon at the top
of the screen will flash 3 times and VBOX Touch
will emit an audible error notification.
IMPORTANT
NEVER remove the SD card while a screenshot is
captured and saved as it could cause the unit to
crash!
VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)
yellow
in sequence from left to
