Racelogic VBOX Touch V2 User Manual page 13

Function
Speed Mode
Screenshot
Reset
Behaviour
When loading a Track Database
file, the progress of the track
database update is displayed via the
LEDs; each lit LED will represent
25% of the process with all LEDs
extinguishing when the process is
complete.
When a Track Layout is changed,
the LEDs will briefly
flash green twice.
When a Finish Line is cleared,
the LEDs will briefly
flash green twice.
When a Standing Start is Enabled
or Disabled, the LEDs will briefly
flash green twice.
If a Target Speed LED Alert has
been set, the LEDs will flash green
when the value is reached.
If a screenshot has been saved
successfully, the LEDs will illuminate
yellow in sequence from left to right
to display the progress of writing to
the SD card.
The LEDs will briefly
flash green twice when a screen
has been reset.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
User_Guide_%E2%80%93_VBOX_Touch_V2/03_LED_Behaviour_%E2%80%93_VBOX_Touch_V2
Colour
13
