If the icon appears white after you have initiated logging,
it means that the unit is primed for logging and is in the
process of synchronising the internal real-time clock
(RTC) to GPS time. The logging will not start until
this synchronisation process is complete.
IMPORTANT
Do not remove the SD card when the Record Icon is red. You may lose data or damage the SD card if you
remove it while the unit is logging.
SD Status
The SD Card Icon displays the status of the recording
media. When an SD card has been inserted and has
free space, the icon will be green. By tapping on the
icon when it is green, you can manually start or stop the
data logging and override the Configured Logging
Strategy.
If the unit cannot detect an SD card or the media is full
or corrupted, the icon will be red.

Satellite Status

The Satellite Icon illustrates whether the unit has a valid
satellite lock.
When a lock is acquired, this icon will be solid green.
If there is no satellite lock, the icon will flash red.

Display Mode

The header shows which Display Mode is currently selected.
