VBOX Touch Accel Mode - Quick Start Guide
VBOX Touch features a 10 Hz GNSS receiver and a responsive colour touchscreen. The Accel Mode allows you to
perform 4 concurrent acceleration tests using specified values.
Registration
So that Racelogic can continue to provide you with notification of the latest software releases, firmware upgrades and to
offer technical support, please register your VBOX Touch.
Register your unit here.
What's Included
VBOX Touch (RLVBTOUCH)
Product Code
VBTOUCH-V1
RLCAB010LE / RLCAB014LE
RLACS313
RLACS262
RLACS277
RLACS281
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/Quick_Start_Guides/VBOX_Touch_Accel_Mode_-
Quantity
1
1
1
1
1
1
Description
VBOX Touch 10 Hz Unit Including
Rubber Cover
Cigar Plug Power Supply
(RLVBTOUCH, 2 m)
or Unterminated Power Supply
(RLVBTOUCH-M, 2 m)
8 GB SD Ultima Pro UHS-1 Memory
Card
GNSS Antenna (3 m)
Swivel Neck Richter Suction Mount
Plastic Carry Case for VBOX Touch
(not supplied with RLVBTOUCH-
M)
_Quick_Start_Guide
1
Advertisement
Table of Contents
Related Manuals for Racelogic VBOX Touch
Summary of Contents for Racelogic VBOX Touch
- Page 1 VBOX Touch Accel Mode - Quick Start Guide VBOX Touch features a 10 Hz GNSS receiver and a responsive colour touchscreen. The Accel Mode allows you to perform 4 concurrent acceleration tests using specified values. Registration So that Racelogic can continue to provide you with notification of the latest software releases, firmware upgrades and to offer technical support, please register your VBOX Touch.
- Page 2 VBOX Touch RTK (RLVBTOUCHR) Product Code Quantity Description VBOX Touch RTK 10 Hz Unit VBTOUCHR-V1 Including Rubber Cover Cigar Plug Power Supply RLCAB010LE (RLVBTOUCH, 2 m) 8 GB SD Ultima Pro UHS-1 Memory RLACS313 Card RLACS308 GNSS Antenna (3 m)
- Page 3 _Quick_Start_Guide...
-
Page 4: Hardware Overview
Hardware Overview Left Side SD Card VBOX Touch logs data via an SD card. Dependent on the Logging Strategy selected within the General Settings area, the unit will either log continuously or when movement is detected (default). More information on this is available here. -
Page 5: Right Side
Antenna VBOX Touch has an internal patch antenna, meaning that in many circumstances where the unit has a clear view of the sky without any interference, an additional antenna is not required. However, if you are struggling to maintain a stable satellite lock, the supplied external antenna (RLACS262) can be connected to the antenna socket. -
Page 6: Screen Overview
Logging VBOX Touch logs data via an SD card inserted in to the Left Side of the Unit. The unit is supplied with an 8 GB SDHC card in a FAT32 file format, which is the only file format supported. If you are looking to purchase a new SD card, it is recommended that any card used has a write speed of above 7 MB/s (4 MB/s absolute minimum) and a speed class of 10 (4 absolute minimum). - Page 7 Setup 1. VBOX Touch has an internal patch antenna, meaning that in many circumstances, where the unit has a clear view of the sky without any interference, an additional antenna is not required. However, if required, mount the supplied external GNSS antenna in the centre of the roof of the vehicle, away from roof bars and other antennas.
- Page 8 7. Select which Accel screen you would like to be shown (Primary, Secondary Best Result) by selecting the Forward and Back arrows on the bottom right of the screen or by swiping the screen left or right. Primary Secondary Best Results https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/Quick_Start_Guides/VBOX_Touch_Accel_Mode_- _Quick_Start_Guide...
- Page 9 Settings. Note: Cannot be used in conjunction with One foot rollout. 12. If you have a VBOX Touch RTK unit and are intending to use RTK corrections, go to RTK Input within the Serial Port Settings and either Enable NTRIP Mode and change the DGPS Baud Rate to 115200 if you are using an...
- Page 10 Note: The external antenna should be used If you are receiving RTK corrections with a VBOX Touch RTK unit. 13. If you have a VBOX Touch RTK unit, it is also possible to change the 3rd tracked constellation between Beidou...
- Page 11 Note: Ensure correct hardware connections are made. 15. Press the Exit Button to return to the Accel Test screen. 16. Take the vehicle outside and wait for the VBOX Touch to gain satellite lock. The Satellite Icon should display as solid green...
- Page 12 17. The unit is now ready to display live Accel Test results. 18. By default, VBOX Touch will automatically start recording when travelling over 0.5 km/h, this can be changed within the General Settings. 19. Tapping on the SD Card Icon...
-
Page 13: Data Analysis
A recorded session will be saved within the SD card as a .vbo file. This can be later analysed using our next generation of data analysis software VBOX Test Suite, which can be downloaded from the VBOX Automotive Website. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/Quick_Start_Guides/VBOX_Touch_Accel_Mode_- _Quick_Start_Guide...
