Appendix | Other Pin Assignments
optoCONTROL 2600
Pin to
controller
(HD-Sub 25)
Controller 7
ODC 1
20
8
21
24
12
Controller 7
ODC 2
20
8
21
24
12
Fig. 61 Pin assignment RS422 between IF2008/PCIE and ODC2600
5 1
10 6
15 11
Fig. 62 15-pin. HD subminiature connector, view on solder pin side of cable connector
25-pin. Signal
Sub-D
1 Error output (Signal)
14 Error output (GND)
Upper tolerance limit
2
(signal)
Upper/ lower tolerance
15
limit (GND)
Lower tolerance limit
3
(signal)
Upper warning limit
16
(signal)
Upper/ lower warning limit
4
(GND)
Lower warning limit
17
(signal)
RS422 reception (negat-
20
ed)
7 RS422 reception (positive) 2
RS422 transmission
8
(positive)
RS422 transmission
21
(negated)
24 Sync signal input (+)
12 Sync signal input (-)
25 Analog output (AGND)
13 Analog output (signal)
Fig. 63 Pin assignment SCD2500-x/IF2008 (15-pin)
IF2008/PCIE interface
card
Socket X1 (or X2)
Sensor 1 (3) TxD+
Sensor 1 (3) TxD-
Sensor 1 (3) RxD+
Sensor 1 (3) RxD-
Sync In+
GND
NC
NC
NC
NC
Sensor 2 (4) TxD+
Sensor 2 (4) TxD-
Sensor 2 (4) RxD+
Sensor 2 (4) RxD-
Sync In+
GND
15-pin. Braids
Sub-D
red
blue
purple
black and brown
white
pink
gray and gray / pink
red / blue
1
4
3
6
15
black (inner conductor)
green
black (outer shield on 25-pin housing)
15-pin
Sub-D,
IF2008
2
1
4
3
6
15
IF2008/PCIE,
7
X1 and X2, 15-
8 pin. Sub-D
9
10
2
1
4
3
6
15
