Measure
optoCONTROL 2600
6.6.3.9

Read Option Data

RD OPT RAM
Name
Description: With this command the currently valid option data is read out from
the main memory.
Command:
Byte 1 Byte 2
„+" „+"
„0" „D"
0x25 0x20
Response:
Byte 1 Byte 2
„0" „D"
0x25 0xA0
0x25 0xE0
Measurement program
number
Language
Displayed measurement unit
Error handling, analog
Serial output format
External light control
Light intensity
Thresshold value for dark/
light transition / Contrast
Reserve 2
Active interface
RS232 Baud rate
RS232 Parity
RS232 Stop bits
RS232 TimeOut Transmit
RS232 TimeOUT Receive
RS422 Baud rate
RS422 Parity
RS422 Stop bits
RS422 TimeOut Transmit
RS422 TimeOUT Receive

6.6.3.10 Write Option Data

WR OPT TO RAM
Name
Description: With this command option data is written from the receive buffer
to the main memory. The validity of the data is checked while this
occurs. If incorrect data is found or a different error arises, the data
is not accepted into the main memory.
Command:
Byte 1 Byte 2
„+" „+"
„0" „D"
0x27 0x20
Byte 3 Byte 4
„+" 0x0D 0x0D2B2B2B
„C" „1"
0x00 0x00
Byte 3 Byte 4
„C" „1"
0x0D 0x00 0x000DA025
0x03 0x00
Binary - 0x0000
Binary - 0x0001
Binary - 0x0000
Binär - 0x0000
Binary - 0x0000
Binary - 0x0000
Binary - 0x0032
Binary - 0x3232
Binary - 0x0000
Binary - 0x0001
Binary - 0x0001C200
Binary - 0x0000
Binary - 0x0002
Binary - 0x0001
Binary - 0x0001
Binary - 0x000A8C00 691200 Bd
Binary - 0x0000
Binary - 0x0002
Binary - 0x0001
Binary - 0x0001
Byte 3 Byte 4
„+" 0x0D 0x0D2B2B2B
„C" „1"
0x0B 0x00
hex
0x3143444F
0x00002025
hex Remark
0x3143444F
Without error
0x0003E025 Error + 4 bytes
error code
Std. - Measurement program
EDGEHL
English
mm
Error output
Binary
Not active
50 %
50 % / 50%
RS232
115200 Bd
None
2
No effect
No effect
None
2
No effect
No effect
hex
0x3143444F
0x000B2027
