Measure
optoCONTROL 2600
6.6.3.5

Change the Measurement Program

CHOOSE MP
Name
Description: The sensor changes the current measurement program.
This corresponds to selecting the measurement program via the
display without the options of saving, i.e. after switching the sensor
off and on the last saved measurement program is loaded.
Command:
Byte 1 Byte 2
„+" „+"
„0" „D"
0x23 0x20
0x02 0x00
Response:
Byte 1 Byte 2
„0" „D"
0x23 0xA0
0x00 0x00
Byte 3 Byte 4
„+" 0x0D 0x0D2B2B2B
„C" „1"
0x01 0x00
0x00 0x00
Byte 3 Byte 4
„C" „1"
0x03 0x00
0x00 0x00
hex Remark
0x3143444F
0x00012023 Command, follow-
ing lenght
(32 bit words)
0x00000002 0 ... EDGEHL
1 ... EDGELH
2 ... DIA
3 ... GAP
4 ... SEG 2 4
5 ... MULTISEG
6 ... USER1
7 ... USER2
8 ... USER3
9 ... USER4
hex Remark
0x3143444F
0x0003A023 Without error
0x00000000 Error code
Page 45
