6.6.3.13 Write Measurement Program Data

WR MPR TO RAM
Name
Description: With this command measurement program data is written from
the receive buffer to the main memory. The validity of the data is
checked while this occurs. If incorrect data is found or a different
error arises, the data is not accepted into the main memory.
Command:
Byte 1 Byte 2
„+" „+"
„0" „D"
0x28 0x20
Description
Measurement program
number
Measurement program
name
Place-holder
Analog offset
Analog gain
Display offset
Display gain
Upper limit
Lower limit
Upper warning
Lower warning
Reserve
Measurement mode
Byte 3 Byte 4
„+" 0x0D 0x0D2B2B2B
„C" „1"
0x0F 0x00
Format Bits Valid values
Type
Binary 16 6 ... 9
unsigned
short
ASCII 8x8 "A" - "Z", " ", " ",
char "0" - "9"
Binary 16
unsigned
short
Binary 32 -10.000 ...
float +10.000
Binary 32 -4.0000 ...
float +4.0000
Binary 32 -99.999 ...
float +99.999
Binary 32 -2.000 ...
float +2.000
Binary 32 -168,876
float ...+168,876
Binary 32
float
Binary 32
float
Binary 32
float
Binary 16 No effect. The factory data are accept-
unsigned ed.
short
Binary 16 0, 1, 2, 3, 4,
unsigned 5, 6, 7
short
hex
0x3143444F
0x000F2028
Remark
6 - USER1
9 - USER4
Only uppercase
letters. The last
space characters
are deleted. Space
characters be-
tween the letters
are replaced by " "
("underscore").
Entry is made in
[ VDC ]
Entry is made in mm
0... NORMAL
1 ... MAX CONT
2 ... MIN CONT
3 ... P-P CONT
4 ... MAX TRIG
5 ... MIN TRIG
6 ... P-P TRIG
7 ... SC1 TRIG
Page 52
