Measure
optoCONTROL 2600
Error
Trigger input
Reset input
Digital / serial
Fig. 36 Measurement mode, example Maximum triggered
Measurement
Error
Trigger input
Reset input
Digital / serial
Fig. 37 Measurement mode, example Momantary value triggered
Measured peak value between
two triggered pulses
Internal
measurement
2.3 kHz
2.3 kHz
2.1 ms
Measurement at time of
trigger pulse
Internal
measurment
Meas 2.3 kHz
2.5 ms
t
Processing time
approx. 1 ms
2.3 kHz
t
Processing time
approx. 1 ms
Meas
Meas 2.3 kHz
2.3 kHz
Page 35
