Measure
optoCONTROL 2600
6.6.3.1

Information Command

INFO
Name
Description: After the command response, sensor data are sent in the ASCII
format.
Command:
Byte 1 Byte 2
„+" „+"
„0" „D"
0x11 0x20
Response with error:
Byte 1 Byte 2
„0" „D"
0x11 0xE0
0x06 0x00
0x00000006 Flash access error
Response without error:
Byte 1 Byte 2
„0" „D"
0x11 0xA0
ArticleNumber:
SerialNumber:
Option:
Measurement range (mm): 40
Reserve:
SoftArtBoot:
SoftArtArm:
SoftArtDSP:
SoftVersionBoot:
SoftVersionARM:
SoftVersionDSP:
6.6.3.2

Start Command

START
Name
Description: Starts the permanent measurement output of the sensor.
Command:
Byte 1 Byte 2
„+" „+"
„0" „D"
0x22 0x20
Response:
Byte 1 Byte 2
„0" „D"
0x22 0xA0
0x00 0x00
Byte 3 Byte 4
„+" 0x0D 0x0D2B2B2B
„0" „1"
0x00 0x00
Byte 3 Byte 4
„C" „1"
0x03 0x00
0x00 0x00
Byte 3 Byte 4
„C" „1"
0x10 0x00
'98765432' ASCII - 8 Byte
'1234567' ASCII - 8 Byte
'000 ' ASCII - 8 Byte
Binär - 0x28000000
Binär - 0xDE83EB3D
'Std ' ASCII - 4 Byte
'Std ' ASCII - 4 Byte
'Std ' ASCII - 4 Byte
1003 Binär - 0xEB030000
1006 Binär - 0xEE030000
1002 Binär - 0xEA030000
Byte 3 Byte 4
„+" 0x0D 0x0D2B2B2B
„0" „1"
0x00 0x00
Byte 3 Byte 4
„C" „1"
0x03 0x00
0x00 0x00
hex
0x3143444F
0x00002011
hex Remark
0x3143444F
0x0003E011 With error +
4 bytes error code
0x00000006 Error code
hex Remark
0x3143444F
0x0010A011 without error
hex
0x3143444F
0x00002022
hex Remark
0x3143444F
0x0003A022 Without error
0x00000000 Error code
Page 43
