1. Introduction
Marks and Symbols
1.4
8
Symbols
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Description
Dangerous voltage
Protective earth (Ground)
Off (power: disconnected to the
Main Power Switch)
On (power: connected to the
Main Power Switch)
Warns ESD hazard.
Location
Power board /
Inverter board /
Monoblock
Column
Main Power
Switch
Main Power
Switch
MCU board /
Board package
