Box No. 2 - Base Unit
3.3.2
Component
Base
Removing the cover
Open the box cover, the Base Cover appears.
1.
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
3. Before Installing the System
Size (mm / inch)
1046 (L) x 1056 (W) x 185 (H) /
41" (L) x 41.5" (W) x 7" (H)
Weight (kg / lbs.)
47 / 103
27
