4. Installing the Equipment: Base Stand (Optional)
Use the Cable Tie (Part No. 20) or Cable Holder (Part No.20) to fix the cables as
2.
shown below after the connection is completed.
56
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
