5. Installing the Equipment: Wall Mount
Combining the Equipment with the Anchor Bolts
Put the aligning plate on the floor while making sure that the align plate's holes
1.
engage in the anchored bolts.
Put the equipment in a vertical position slowly while holding the upper handle as
2.
shown in the figure.
68
Be careful not to damage the cables before erecting the
equipment. Keep them clear of the equipment.
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
