Marks and Symbols

Symbols
Alternate current
Attention:
consult accompanying documents
Dangerous voltage
Protective earth (Ground)
Off
(power: disconnect from the main switch)
On (power: connect to the main switch)
TYPE B Equipment
Radiation hazard
EC representative
The CE symbol indicates that this product
complies with the European Directive for
Medical Devices 93/42/EEC as amended by
0434
2007/47/EC as a class IIb device.
UL mark: UL 60601-1 / CAN/CSA
C22.2 No.601.1 3ZY1
A d d r e s s w h e r e t h e e q u i p m e n t w a s
manufactured
This symbol indicates that electrical and
electronic equipment must not be disposed
of as unsorted municipal waste and must be
collected separately.
This symbol warns ESD hazard.
This symbol indicates that this equipment is
classified as a CLASS 1 LASER PRODUCT in
accordance with IEC 60825-1 ED.1 regulations.
Date of manufacture
Refer to Instruction manual
3 PaX-i3D Green Imaging System Overview
Description Location
-
Label
Power board
Power board
Main switch
Main switch
Label
Label
Label
Label
Label
Label
Label
MCU board/
Board package
Label
Label
Label
41
