Setting up PC's Environment Variables

8.

Before Beginning

8.1
Checking PC BIOS Settings
Generally, the PC is shipped, with its BIOS settings, as specified in Appendix E:
Checking PC BIOS Settings. Before proceeding to the next sections, check the
BIOS status.
In case the BIOS settings have not been configured in advance or the settings are
different, however, please follow the steps below.
Reboot the PC and go into the BIOS setting mode.
1.
Set the variables as in the table below.
2.
Main Menu
Advanced
Advanced
Advanced
When you update the BIOS settings, the "Enhanced Halt State (C1E)" option will be
⚫
displayed.
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
8. Setting up PC's Environment Variables
Disregard this section in case the PC system is supplied with
the equipment. (The environment variables of the PC have
already been set on the PC.)
▪ Ensure that the Emergency Stop Switch is in the OFF
position before starting with the InstallShield
installation.
▪ Do not install the programs irrelevant to image
acquisition and view on the same PC. There may be
subtle conflicts between them, leading to the
malfunction.
▪ The PC system supplied with the equipment is intended
to be used as an image acquisition only. For the PC
server for image management, it is strongly
recommended to use a different PC.
▪ The programs related to the acquisition, viewing, and
manipulation of images should be installed on the
formatted PC, where no other program(s) except the
operating system (OS) is present.
▪ Before InstallShield installation, ensure that the video
card driver installed on the PC is the most up-to-date
version. To check this, go to the website of the graphics
card manufacturer.
PC BIOS default
Sub1 Menu
Power Options Runtime Power Management
Power Options
Power Options Enhanced Halt State (C1E)
Sub2 Menu
Idle Power Savings
Setup Value
[Disable]
[Normal]
[Disable]
87
