Installing the Internal Peripherals

7.3
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Allow enough time to dissipate remnant energy after
unplugging the power cord from the main outlet or PC.
▪ Disregard this section in case the PC system is supplied
with the equipment. (The peripherals have already been
installed inside the PC.)
▪ Whenever handling the fiber optic frame grabber board:
1. Wear the anti-static glove.
2. Do not wear the likes of a thick jacket.
The following figures and descriptions are based on the PC
model Z440 from HP.
7. Setting up PC
83
