Put the equipment in a vertical position slowly while holding the upper handle.
4.
Tighten the three Wrench Bolts to attach the base unit.
5.
Allen Wrench
Wrench Bolt
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
4. Installing the Equipment: Base Stand (Optional)
Be sure not to damage the cables. Before erecting the
equipment, keep them clear of the equipment.
8 mm / 0.31"
M10 x 20
w/ Spring
(Part No.23)
41
