Troubleshooting

Troubleshooting

Required Equipment

Fault Isolation Procedure

4–52
WARNING. To prevent possible injury to service personnel or damage to electrical
components, please read Preventing ESD on (See page 4-1, Preventing ESD.).
WARNING.
Before performing this or any other procedure in this manual, read the
General Safety Summary and Service Safety Summary found at the beginning of
this manual.
This section contains information and procedures designed to help you isolate
faults to a module.
This section requires that service personnel have the appropriate skills to work on
this instrument, including PC troubleshooting and Microsoft Windows operating
system skills. Details of PC and Windows operation and service are not in this
manual.
For assistance, contact your local Tektronix Service Center.
You will need a digital multimeter to check power supply voltages, as described
on (See page 4-55, Checking the Power Supply Voltages.).
Follow the primary troubleshooting tree on the following two pages for fault
isolation.
