Table 4-7: Calibration error codes (cont.)
Error code Error log message
200XP0011 Analog Level Calibration CHX internal offset 10bit
failed. expected 0.0mV, actual xxxxxmV
200XP0012
Analog Level Calibration CHX can't find 8bit outamp
offset cross point. expected 0.0mV, actual pos:
xxxxxmV, neg: xxxxxmV
200XP0013
Analog Level Calibration CHX can't find 10bit outamp
offset cross point. expected 0.0mV, actual pos:
xxxxxmV, neg: xxxxxmV
200XP0015
Analog Level Calibration CHX 5db attenuator gain
balance failed.
200XP0016 Analog Level Calibration CHX 5db attenuator gain
balance failed.
200XP0017 Analog Level Calibration CHX 10db attenuator gain
balance failed.
200XP0018 Analog Level Calibration CHX 20db attenuator gain
balance failed.
200XP0019 Analog Level Calibration CHX filter 50mhz gain balance
failed.
200XP0020 Analog Level Calibration CHX filter 200mhz gain
balance failed.
200XP0021 Analog Level Calibration CHX amp gain balance failed.
210XM0001 Marker Level Calibration CHX MARKER M offset failed.
210XM0002
Marker Level Calibration CHX MARKER M positive
offset failed.
210XM0003 Marker Level Calibration CHX MARKER M negative
offset failed.
210XM0004 Marker Level Calibration CHX MARKER M amplitude
failed.
210XM0005 Marker Level Calibration CHX MARKER M amplitude
correction failed.
211XMP006 Marker Level Calibration CHX MARKER M
positive(negative) input level failed.
220000000 HwExecMarkerDelayCal (channel=1) A maximum and a
minimum difference are smaller than 80ps at coarse=15
220000001 HwExecMarkerDelayCal (channel=2) A maximum and a
minimum difference are smaller than 80ps at coarse=15
220000002 HwExecMarkerDelayCal (channel=1) Frequency
measurement cannot be performed.
220000003 HwExecMarkerDelayCal (channel=2) Frequency
measurement cannot be performed.
AWG7000B and AWG7000C Series Service Manual
Possible defect
on board Note
OUT10G AWG10G: U100A/B, U150A/B
AWG12G AWG12G: U100A/B, U150A/B
AWG12G AWG12G: U100A/B, U150A/B
OUT10G OUT10G: U120, U170, U230,
U240, U330, U340
OUT10G OUT10G: U120, U170, U230,
U240, U330, U340
OUT10G OUT10G: U120, U170, U230, 240,
U330, U340
OUT10G OUT10G: U120, U170, U230,
U240, U330, U340
OUT10G OUT10G: U120, U170, U230,
U240, U330, U340
AWG12G AWG12G: U1000, U100A/B
AWG12G AWG12G: U1000, U100A
AWG12G AWG12G: U1000, U100B
AWG12G AWG12G: U1000, U100A
AWG12G AWG12G: U1000, U100B
