Replaceable Parts
Table 5-9: Replaceable parts list – AWG7000C Series Processor module
Fig. & index Tektronix
number part number
5-9-
-1 407-5195-01
-2 211-1050-00
-3 343-1627-00
-4 343-1636-00
-5 346-0128-00
-6 343-1701-00
-7 211-1050-00
-8 039-0188-00
-9 167-1493-00
-10 119-7632-00
-11 167-1348-00
-12 342-1153-00
-13 441-2626-00
-14 214-3903-00
5–16
Serial no. Serial no.
effective discont'd Qty Name & description
PROCESSOR MODULE
1 BRACKET;DRIVE BAY UNIT
10 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 CABLE,CLAMP; 0.5H X 2.98L,0.625 W,NYLON 6-6,ADHESIVE,COVER
343-1636-00
1 CLAMP, COVER; FLT CABLE ROUTING CLAMP, 343-1627-00 BASE
2
STRAP,TIEDOWN;8.0 L X 0.1 W,NYLON
2 CLAMP,CABLE; WITH ADHESIVE BACK
8 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 COMPUTER BOARD;ADVANTECH, MICROATX, LGA 775 CORE 2
DUO, DDR2, PCI-E X4, DUAL CH LVDS, DVI-I, SINGLE GBE LAN;
ADVANTECH AIMB-566, SAFETY CONTROLLED
2 IC, MEMORY;256MBIT X 64, 2GB DDR2 1.8V, 6-6-6, 800 MT/S;
MT16HTF25664AY-800, DIMM240, PC6400
1 FAN, TUBEAXIAL; 12VDC, 0.40A, 4.80W, 2500RPM, 100.6CFM,
120MM, W/LEADS; SAFETY CONTROLLED
1 PROCESSOR; INTEL CORE 2 DUO, 3.0 GHZ, WOLFDALE, E8400;
65W; BUS SPD 1333MHZ; FC-LGA775 PKG, W/O FAN AND HEATSINK
1 INSULATOR; PLATE,MOTHER BOARD,0.04 POLYCARBONATE,
TAPPEN
1 CHASSIS,TRAY,PROCESSOR, SAFETY CONTROLLED
6
SCREW,JACK; 4-40 X 0.312 LONG,0.188 H HEX HEAD STAND OFF,
4-40 INT THD, X 0.312 THD EXT 4-40
