Replaceable Parts
Table 5-10: Replaceable parts list – AWG7000B Series processor module
Fig. & index Tektronix
number part number
5-10-
-1 407-5195-01
-2 211-1050-00
-3 346-0128-00
-4 343-1701-00
-5 211-1050-00
-6 167-1048-00
167–1515–00
-7 119-7333-00
-8 167-0710-00
-9 335-0577-00
-10 342-1153-00
-11 441-2542-00
-12 407-5320-00
-13 211-1050-00
-14 214-3903-00
-15 065-0813-02
650-5305-00
5–18
Serial no. Serial no.
effective discont'd
B010000 B019999
B020000
Qty Name & description
PROCESSOR MODULE
1 BRACKET;DRIVE BAY UNIT
10 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
2 STRAP,TIEDOWN;8.0 L X 0.1 W,NYLON
2 CLAMP,CABLE; WITH ADHESIVE BACK
8
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 IC, MEMORY;128M X 64, 1GB DDR2 1.8V, 3-3-3, 667
MHZ;MT8HTF12864AY-667E1, DIMM240, DS1
1 IC MEMORY, DRAM MODULE; 2GB DDR2 PC5300
1 P4 LGA775 FAN-SINK-BRACKET FROM AVC
1 PROCESSOR; CELERON D, 2.93 GHZ,LEAD-FREE, 1.287V TO 1.4V
CORE,84W,BUS SPD 533MHZ,FC-LGA4 775 PKG, W/O FAN and
HEATSINK,HH80547RE077CN,INTEL
1 MARKER,IDENT;MKD MAC ADDRESS LABEL
1 INSULATOR; PLATE,MOTHER BOARD,0.04 POLYCARBONATE,
TAPPEN
1 CHASSIS,TRAY,PROCESSOR,TAPPEN, SAFETY CONTROLLED
1 BRACKET,CONN; AL,0.063 THICK,W/131641700 EMI CLIPS
3 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
6 SCREW,JACK; 4-40 X 0.312 LONG,0.188 H HEX HEAD STAND OFF,
4-40 INT THD, X 0.312 THD EXT 4-40
1 MODULE; PROCESSOR
1 MODULE; PROCESSOR, REPROGRAMMED BIOS TO 62X1182C
