Tektronix AWG7000B Series Service Manual page 41

Data Timing-RAM Timing
Calibration
Data Timing-PLD Timing
Calibration
Analog Output Level
Calibration
Marker Output Level
Calibration
Marker Delay Calibration
Marker Output Cross Point
Calibration
Inter-Channel Skew
Calibration (AWG7122C,
AWG7082C, AWG7122B,
and AWG7062B)
AWG7000B and AWG7000C Series Service Manual
This is a self calibration. The instrument outputs a waveform while reading
the waveform data from the internal RAM to the Memory Controller PLD.
This calibration ensures the optimum timing to enable waveform outputs in all
frequency settings. If you fail to perform the calibration, a waveform data may
not be read from the waveform memory correctly.
This is a self calibration. The instrument outputs a waveform while transferring a
waveform data from the Memory Controller PLD to the ASIC of the following
stage. This calibration ensures the optimum timing to enable waveform outputs
in all frequency settings. If you fail to perform the calibration, a waveform data
cannot be transferred properly, and the waveform may not be output normally.
This is a self calibration. This calibration ensures that the analog output levels
are within the specified range.
This is a self calibration. This calibration ensures that the marker output levels
are within the specified range.
This is a self calibration. This calibration ensures that the marker delay is within
the specified range.
This is a self calibration. This calibration ensures that the marker output cross
point is within the specified range.
This calibration ensures that the Ch 1 and Ch 2 output skews are set within the
specified range. This calibration is applied to both analog and marker outputs.
Equipment required
One sampling oscilloscope
Two 50 Ω SMA 12 dB attenuators
Two 50 Ω SMA cables
Three 50 Ω SMA terminations
Adjustment Procedures
Prerequisites
20 minute warm-up at 20 °C to 30 °C
3–7
