Using The Replaceable Parts List - Tektronix AWG7000B Series Service Manual

Replaceable Parts
Module Servicing

Using the Replaceable Parts List

Parts List Column Descriptions
Column Column name
1 Figure & Index
Number
2 Tektronix Part
Number
3 and 4 Serial Number
5 Qty
6 Name & Description
Abbreviations
5–2
Modules can be serviced by selecting one of the following three options. Contact
your local Tektronix service center or representative for repair assistance.
Module Exchange. In some cases, you may exchange your module for a
remanufactured module. These modules cost significantly less than new modules
and meet the same factory specifications. For more information about the
module exchange program, call 1-800-833-9200. Outside North America,
contact a Tektronix sales office or distributor; see the Tektronix Web site
(www.tektronix.com) for a list of offices.
Module Repair and Return. You may ship your module to us for repair, after
which we will return it to you.
New Modules. You may purchase replacement modules in the same way as other
replacement parts.
This section contains a list of the replaceable mechanical and/or electrical
components. Use this list to identify and order replacement parts. The following
table describes each column in the parts list.
Description
Items in this section are referenced by component number.
Use this part number when ordering replacement parts from Tektronix.
Column three indicates the serial number at which the part was first effective. Column four
indicates the serial number at which the part was discontinued. No entries indicates the part is
good for all serial numbers.
This indicates the quantity of parts used.
An item name is separated from the description by a colon (:). Because of space limitations,
an item name may sometimes appear as incomplete. Use the U.S. Federal Catalog handbook
H6-1 for further item name identification.
Abbreviations conform to American National Standard ANSI Y1.1-1972.
AWG7000B and AWG7000C Series Service Manual
