Table 5-21: Replaceable Parts List - Relay Unit - Tektronix AWG7000B Series Service Manual

Table 5-21: Replaceable parts list – relay unit
Fig. & Tektronix
index part
number number
5-21-
-1 174-5821-00
174-5821-00
-2 441-2461-00
-3 174-5338-00
-4 211-1050-00
-5 343-1715-00
-6 015-0720-00
-7 407-5198-00
-8 211-A273-01
211-A273-01
-9 174-5339-00
-10 174-5250-00
174-5250-00
-11 148-0341-00
148-0341-00
AWG7000B and AWG7000C Series Service Manual
Serial no.
Model effective
AWG7121B
Option 02
AWG7122C
Option 06
AWG7122B
Option 06
AWG7122C
Option 06
AWG7122B
Option 06
AWG7122C
Option 06
AWG7122B
Option 06
AWG7122C
Option 06
AWG7122B
Option 06
AWG7122B
Option 06
AWG7122C
Option 06
AWG7122B
Option 06
AWG7121B
Option 02
AWG7122C
Option 06
AWG7122B
Option 06
AWG7122B
Option 06
AWG7121B
Option 02
AWG7122C
Option 06
AWG7122B
Option 06
AWG7121B
Option 02
AWG7122C
Option 06
AWG7122B
Option 06
Serial no.
discont'd Qty Name & description
RELAY UNIT (Option 02/06 only)
1 CABLE ASSY ELEC: 10P, 0.1, 8IN L, 3P RIBBON X 2, FOR
148036800 RF RELAY
4 CABLE ASSY ELEC: 10P, 0.1, 8IN L, 3P RIBBON X 2, FOR
148036800 RF RELAY
1 CHASSIS, RELAY UNIT
1 CABLE ASSY ELEC: RF,COAX,4.4IN L,50 OHM,SMA-P
STR, SMA-P STR,W/LABEL, MATCHED DELAY FLEX COAX
CABLE
4
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
2 RETAINER;FOR RF POWER SPLITTER 015072000
1515-1 AEROFLEX/WEINSCHEL INC
2
POWER DIVIDER; 50 OHM,1 WATT,DC TO 18.0 GHZ,SMA
FEMALE TO TWO SMA FEMALES,1515-1
1 BRACKET;FOR RF POWER SPLITTER 015072000
1515-1 AEROFLEX/WEINSCHEL INC
4 SCREW,MACHINE; M2.5X18 L,PNH,STL,NI PL,CROSS
REC, W/FLAT & LOCK WASHER
16 SCREW,MACHINE; M2.5X18 L,PNH,STL,NI PL,CROSS
REC, W/FLAT & LOCK WASHER
2 CABLE ASSY ELEC: RF,COAX,6IN L,50 OHM,SMA-P STR,
SMA-P STR,W/LABEL, MATCHED DELAY FLEX COAX
CABLE
2
CABLE ASSY ELEC: RF,COAX,10IN L,50 OHM,SMA-P STR,
PELTOLA,W/MARK BAND, FLEX COAX CABLE
4 CABLE ASSY ELEC: RF,COAX,10IN L,50 OHM,SMA-P STR,
PELTOLA,W/MARK BAND, FLEX COAX CABLE
2 RELAY;ARMATURE;8H ANNEALING, 2 FORM C, 5 GHZ,
50 OHM, IL 0.5DB AT 5GHZ, 1W, SINGLE STABLE, COIL
12VDC, 720 OHM;ARJ20A12XJ01, 0.551L X 0.354W X
0.323H, 10 PIN SMD, T&R
8 RELAY;ARMATURE;8H ANNEALING, 2 FORM C, 5 GHZ,
50 OHM, IL 0.5DB AT 5GHZ, 1W, SINGLE STABLE, COIL
12VDC, 720 OHM;ARJ20A12XJ01, 0.551L X 0.354W X
0.323H, 10 PIN SMD, T&R
Replaceable Parts
5–39
