Table 4-7: Calibration error codes (cont.)
Error code Error log message
263XY1108 Invalid phase transition distance at CH2, TEK0015-X
bit Y.
270000000 HwExecYigCal PLL read error
270000001 HwExecYigCal PLL 6GHz offset under 2048 vtune=xxxx
270000002 HwExecYigCal PLL 6GHz offset underflow vtune=xxxx
270000003
HwExecYigCal PLL 6GHz tuning underflow vtune=xxxx
270000004 HwExecYigCal PLL 6GHz tuning underflow vtune=xxxx
270000005 HwExecYigCal PLL 12GHz tuning over 4095
vtune=xxxx
270000006 HwExecYigCal PLL 12GHz tuning overflow vtune=xxxx
271000001 HwExecYigCal PLL 6GHz offset under 2048 vtune=xxxx
271000002 HwExecYigCal PLL 6GHz offset underflow vtune=xxxx
271000003 HwExecYigCal PLL 6GHz tuning underflow vtune=xxxx
271000004 HwExecYigCal PLL 6GHz tuning underflow vtune=xxxx
271000005 HwExecYigCal PLL 12GHz tuning over 4095
vtune=xxxx
271000006
HwExecYigCal PLL 12GHz tuning overflow vtune=xxxx
272000000 Clock Power CAL failed
272000001 Clock Power CAL failed at 6 GHz
272000002 Clock Power CAL failed at 12 GHz
290000000 Marker Level Calibration has not been completed.
290000001 Marker cross point calibration result exceeds limit.
290X00000 Marker Level Calibration has not been completed at
CHX.
290XY0001 Marker cross point calibration result exceeds limit at
CHX, MARKER Y.
290XY0002 Marker cross point calibration couldn't be converged on
-1.0V at CHX, MARKER Y.
291000000 Marker Level Calibration has not been completed.
291000001 Marker cross point calibration result exceeds limit.
291X00000 Marker Level Calibration has not been completed at
CHX.
AWG7000B and AWG7000C Series Service Manual
Possible defect
on board Note
AWG12G AWG12G: U100B, U300B (X=0,1
-> P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G: U1000, U1040
CLK12G CLK12G:U3200, U3250, Y3280
CLK12G CLK12G:U3200, U3250, Y3280
CLK12G CLK12G:U3200, U3250, Y3280
CLK12G CLK12G:U3200, U3250, Y3280
CLK12G CLK12G:U3200, U3250, Y3280
CLK12G CLK12G:U3200, U3250, Y3280
CLK12G CLK12G: U3200, U3250, Y3280
CLK12G CLK12G: U3200, U3250, Y3280
CLK12G CLK12G: U3200, U3250, Y3280
CLK12G CLK12G: U3200, U3250, Y3280
CLK12G CLK12G: U3200, U3250, Y3280
CLK12G CLK12G: U3200, U3250, Y3280
N/A
OUT10G OUT10G: U120, U170
N/A
OUT10G, OUT10G: U120/170, U470/480,
AWG12G J100/110/150/170 AWG12G:
J110A/111A/115A/
116A/110B/111B/115B/116B
OUT10G, OUT10G: U120/170, U470/480,
AWG12G J100/110/150/170 AWG12G:
J110A/111A/115A/
116A/110B/111B/115B/116B
N/A
N/A
N/A
Troubleshooting
4–71
