Troubleshooting
Table 4-7: Calibration error codes (cont.)
Error code Error log message
263XY0021 The Cal value is not found at TEK0015-X bit
Y.(tek15_ch1_timing_1)
263XY0022 The Cal value is not found at TEK0015-X bit
Y.(tek15_ch2_timing_1)
263XY0023 The Cal value is not found at TEK0015-X bit
Y.(tek15_ch1_timing_2)
263XY0024 The Cal value is not found at TEK0015-X bit
Y.(tek15_ch2_timing_2)
263XY0041
The Cal value is not found at TEK0015-X bit
Y.(tek15_ch1_timing_3)
263XY0042 The Cal value is not found at TEK0015-X bit
Y.(tek15_ch2_timing_3)
263XY0121 The difference between tek15_ch1_timing_1 and
tek15_ch2_timing_1 is larger than 120ps at TEK0015-X
bit Y.
263XY0123 The difference between tek15_ch1_timing_2 and
tek15_ch2_timing_2 is larger than 120ps at TEK0015-X
bit Y.
263XY1009 Invalid NG Areas at CH1 TEK0015-X bit Y.
263XY1010
Invalid NG Areas at CH2 TEK0015-X bit Y.
263XY1101 Too large delay value was set for TEK0015-X bit Y.
263XY1102 Too large delay value was set for TEK0015-X bit Y.
263XY1103 Too large delay value was set for TEK0015-X bit Y.
263XY1104 Too large delay value was set for TEK0015-X bit Y.
263XY1105 Too large delay value was set for TEK0015-X bit Y.
263XY1107 Invalid phase transition distance at CH1 TEK0015-X
bit Y.
4–70
Possible defect
on board Note
AWG12G AWG12G:U100A, U300A (X=0,1 ->
P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G:U100A, U300B (X=0,1 ->
P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G:U100A, U300A (X=0,1 ->
P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G:U100A, U300B (X=0,1 ->
P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G:U100A, U300PA
AWG12G AWG12G:U100B, U300PB
AWG12G AWG12G:U100A/B, U300A/B
AWG12G AWG12G:U100A/B, U300A/B
AWG12G AWG12G:U100A, U300A
AWG12G AWG12G:U100B, U300B
AWG12G AWG12G: U100A/B, U300A/B
(X=0,1 -> P; X=2,3 -> Q; X=4,5 ->
R; X=6,7 -> S; X=8,9 -> T)
AWG12G AWG12G: U100A, U300A (X=0,1
-> P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G: U100B, U300B (X=0,1
-> P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G: U100A, U300A (X=0,1
-> P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G: U100B, U300B (X=0,1
-> P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
AWG12G AWG12G: U100A, U300A (X=0,1
-> P; X=2,3 -> Q; X=4,5 -> R; X=6,7
-> S; X=8,9 -> T)
