Maintenance

Troubleshooting Aids

Foldout Pages
7–2
8. Avoid handling components in areas that have a floor or work surface
covering capable of generating a static charge.
9. Use a soldering iron that is connected to earth ground.
10. Use only special antistatic, suction-type or wick-type desoldering tools.
The following is miscellaneous information about schematics, circuit board
illustrations, component numbering, and assembly numbering.
NOTE. No repair should be attempted during the warranty period.
The foldout pages at the back of the manual contain block and schematic
diagrams and circuit board illustrations. See Figure 7–1.
CIRCUIT BOARD
ILLUSTRATIONS
À À À À À À À À
À À À À À À À À
À À À À À À À À
À À À À À À À À
           Â
           Â
PARTS LOCATING
CHART
THEORY OF OPERATION OR
ADJUSTMENT PROCEDURE
Figure 7–1: Using the Foldout Pages
SCHEMATIC
SCHEMATIC
VITS 200
