Tektronix AWG7000B Series Service Manual page 117

Table 4-6: Diagnostics error codes (cont.)
Error code Error log message
151000015 Analog Level Diag CH2 5db attenuator gain balance
failed.
151000016
Analog Level Diag CH2 5db attenuator gain balance
failed.
151000017 Analog Level Diag CH2 10db attenuator gain balance
failed.
151000018 Analog Level Diag CH2 20db attenuator gain balance
failed.
151000019 Analog Level Diag CH2 filter 50mhz gain balance failed.
151000020
Analog Level Diag CH2 filter 200mhz gain balance
failed.
151000021 Analog Level Diag CH2 amp gain balance failed.
1520M0001 Marker Level Diag CH2 MARKER M offset failed.
1520M0002 Marker Level Diag CH2 MARKER M positive offset
failed.
1520M0003 Marker Level Diag CH2 MARKER M negative offset
failed.
1520M0004
Marker Level Diag CH2 MARKER M amplitude failed.
1520M0005 Marker Level Diag CH2 MARKER M amplitude
correction failed.
190000000 TekLink receive error Send=TR Recv=RV
TR:Transmition data RV:Receive data
AWG7000B and AWG7000C Series Service Manual
Possible defect
on board Note
OUT10G OUT10G: K610, K710
OUT10G OUT10G: K610, K710
OUT10G OUT10G: K620, K720
OUT10G OUT10G: K630, K730
OUT10G OUT10G: K660, K760
OUT10G OUT10G: K670, K770
OUT10G OUT10G: U800
OUT10G U120, U170, U230, U240, U330,
U340
OUT10G U120, U170, U230, U240, U330,
U340
OUT10G U120, U170, U230, U240, U330,
U340
U120, U170, U230, U240, U330,
OUT10G
U340
OUT10G U120, U170, U230, U240, U330,
U340
MIO MIO: U300
Troubleshooting
4–63
