AWG7000B and AWG7000C Series Service Manual
The cable at J120 from the CH2 OUT10G board to the Channel 2 Mkr
1 connector.
The cable at J130 from the CH2 OUT10G board to the Channel 2 Mkr
1 connector.
The cable at J160 from the CH2 OUT10G board to the Channel 2 Mkr
1 connector.
The cable at J190 from the CH2 OUT10G board to the Channel 2 Mkr
1 connector.
7. Remove the four screws securing the CH2 OUT10G board to the chassis.
8. Lift the board away from the chassis.
Installation. To install, reverse this procedure.
Removal and Installation Procedures
4–51
