Replaceable Parts
Table 5-12: Replaceable parts list – AWG7000B series power supply assembly
Fig. & index Tektronix
number part number
5-12-
-1 119-6986-03
-2 211-1050-00
-3 407-5145-01
-4 211-1050-00
-5 174-5269-00
-6 211-1050-00
-7 407-5369-00
-8 211-1050-00
5–22
Serial no. Serial no.
effective discont'd Qty Name & description
POWER SUPPLY ASSEMBLY
1 POWER SUPPLY; AC-DC;460W;+3.3V 40A,+5V 34A,+12V 25A,
-12V 1A,+5VSB 2A;90-264VAC,47-63HZ;BERG 51624-XX001;
9.5X4.9X3.8IN,SAFETY CONTROLLED
6 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 BRACKET, POWER SUPPLY
3 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 CABLE ASSY; AC INLET TO CKT BD,14 IN L,AWG16 X 3,
W/FN9222-10/06 FILTER/1-480700 CONN
4 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 BRACKET, SUPPORT; ANTI-SHOCK, DUMMY POWER SUPPLY, .063
ALUMINUM WITH 2 SORTS OF ABSORBERS ATTACHED
(AWG7000B SERIES ONLY)
4 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
(AWG7000B SERIES ONLY)
