Troubleshooting
Table 4-6: Diagnostics error codes (cont.)
Error code Error log message
122000001 HwDiagWaveformMemory channel=2,
MemoryController-P Address Bus Error
Address=0xXXXXXXXX RAM/PLD-pinName
expected data=xxxxxxxx actual data=xxxxxxxx P:
PLD number RAM/PLD-pinName:U5x0yy-pinRam /
U400zz-pinPld
122000002 HwDiagWaveformMemory channel2,
MemoryController-P Cell HL Error P: PLD
number HL: U5x0yy
122000003
HwDiagWaveformMemory channel=2,
MemoryController-P Invert Bit bus RAM/PLD-pinName
testNo-testCnt Error expected data=xxxxxxxx
actual data=xxxxxxxx P: PLD number
RAM/PLD-pinName:U5x0yy-pinRam / U400zz-pinPld
testNo:1'st or 2'nd testCnt:1'st - 4'th
130000000 HwDiagClockRegister PLL_MUX_HIGH=0
130000001 HwDiagClockRegister PLL_MUX_LOW=1
131000000
HwDiagClockPll 7.5GHz YIG tuning error
131000001 HwDiagClockPll 7.5GHz PLL Unlocked
131000002 HwDiagClockPll 1GHz PLL Locked
131000003 HwDiagClockPll 4.9GHz YIG tuning error
131000004 HwDiagClockPll 4.9GHz PLL Unlocked
131000005
HwDiagClockPll 10.1GHz YIG tuning error
131000006 HwDiagClockPll 10.1GHz PLL Unlocked
140000000 The error occurred in the EEPROM read. 1st=FST
2nd=SND FST: the data that is received from EEPROM
at the first read check SND: the data that is received
from EEPROM at the second read check, which is
implemented after writing 0x55 to EEPROM
140000001 Message varies depending on the situation.
1410P0001 Analog Level Diag CH1 positive (negative) 5db
attenuator failed. expected 0.56234, actual xxxxx
4–60
Possible defect
on board Note
AWG12G P=0 -> U400PB, U500PB, U510PB
P=1 -> U400QB, U500QB, U510QB
P=2 -> U400RB, U500RB, U510RB
P=3 -> U400SB, U500SB, U510SB
P=4 -> U400TB, U500TB, U510TB
AWG12G P=0 -> U500PB, U510PB P=1 ->
U500QB, U510QB P=2 -> U500RB,
U510RB P=3 -> U500SB, U510SB
P=4 -> U500TB, U510TB
P=0 -> U400PB, U500PB, U510PB
AWG12G
P=1 -> U400QB, U500QB, U510QB
P=2 -> U400RB, U500RB, U510RB
P=3 -> U400SB, U500SB, U510SB
P=4 -> U400TB, U500TB, U510TB
AWG12G, AWG12G: U1000 CLK12G: U3200
CLK12G
AWG12G, AWG12G: U1000 CLK12G: U3200
CLK12G
AWG12G, AWG12G: U1000, U1040 CLK12G:
CLK12G U3200, U3250, Y3100, Y3280
AWG12G, AWG12G: U1000, U1040 CLK12G:
CLK12G U3200, U3250, Y3100, Y3280
AWG12G, AWG12G: U1000 CLK12G: U3200
CLK12G
AWG12G, AWG12G: U1000, U1040 CLK12G:
CLK12G U3200, U3250, Y3100, Y3280
AWG12G, AWG12G: U1000, U1040 CLK12G:
CLK12G U3200, U3250, Y3100, Y3280
AWG12G, AWG12G: U1000, U1040 CLK12G:
CLK12G U3200, U3250, Y3100, Y3280
AWG12G, AWG12G: U1000, U1040 CLK12G:
CLK12G U3200, U3250, Y3100, Y3280
OUT10G OUT10G-CH1: U500, U550
OUT10G OUT10G-CH1: U500, U550
OUT10G OUT10G: K610, K710
