Tektronix AWG7000B Series Service Manual page 128

Troubleshooting
Table 4-8: Hardware error codes (cont.)
Error code Error log message
300000104 Access to EEPROM failed on AWG board.
300000200 The download (MIO-INIT) timeout period has
expired.
300000201 The download (MIO-INIT) timeout period has
expired.
300000202 The download (MIO-DONE) timeout period has
expired.
300000203 The download (MIO) timeout period has expired.
300000204 The system cannot find the file
specified.(PLD140b.Bit)
300000205 An attempt was made to load a program with an
incorrect format.(PLD131.Bit)
300000206 The download(AwgController-INIT) timeout period
has expired.
300000207 The download(AwgController-INIT) timeout period
has expired.
300000208 The download(AwgController-DONE) timeout
period has expired.
300000209
The download (AwgController) timeout period has
expired.
300000210 The system cannot find the file
specified.(PLD231.Bit)
300000211 An attempt was made to load a program with an
incorrect format.(PLD231.Bit)
300000212 The download (MemoryController-INIT) timeout
period has expired.
300000213 The download (MemoryController-INIT) timeout
period has expired.
300000214
The download (MemoryController-DONE) timeout
period has expired.
300000215 The download (MemoryController) timeout period
has expired.
300000216 The system cannot find the file
specified.(PLD230b.Bit)
300000217 An attempt was made to load a program with an
incorrect format.(PLD230b.Bit)
300000218 The DCM timeout period has expired.
300000219 The LOCKED timeout period has expired.
300000220 A PLD231.Bit file is old version.
300000221
A PLD230.Bit file is old version.
4–74
Possible defect
on board Note
AWG12G AWG12G: U1090
MIO MIO: U200, U300
MIO MIO: U200, U300
MIO MIO: U200, U300
MIO MIO: U200, U300
N/A Software
N/A Software
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO-AWG12G Cable
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO-AWG12G Cable
MIO, AWG12G MIO: U300 AWG12G: U1000
MIO-AWG12G Cable
N/A Software/Disk Drive
N/A Software/Disk Drive
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
MIO, AWG12G MIO: U300 AWG12G: U1000, U400xx
N/A Software/Disk Drive
N/A Software/Disk Drive
MIO MIO: U300
MIO MIO: U300
N/A Software/Disk Drive
N/A Software/Disk Drive
AWG7000B and AWG7000C Series Service Manual
