Table 5-20: Replaceable Parts List - Sma Bracket - Tektronix AWG7000B Series Service Manual

Table 5-20: Replaceable parts list – SMA bracket
Fig. & Tektronix
index part
number number
5-20-
-1 407-5144-00
-2 211-0734-00
-3 407-5222-00
-4 131-8054-00
-5 174-5244-00
-6 174-5344-00
174-5344-00
-7 174-5343-00
174-5343-00
-8 174-5337-00
174-5337-00
AWG7000B and AWG7000C Series Service Manual
Serial no.
Model effective
AWG7xx1B
AWG7xx2C
AWG7xx2B
AWG7xx1B
AWG7xx2C
AWG7xx2B
AWG7121B
Option 02
AWG7122C
Option 06
AWG7122B
Option 06
Serial no.
discont'd Qty Name & description
SMA BRACKET
1 BRACKET, SMA: FRONT I/O
5 SCREW,MACHINE; 6-32 X 0.250,FLH100,STL,CDPL,T-10
TORX DR
1 BRACKET, SMA: FRONT I/O BNC AREA
2
CONN,RF,JACK; BNC,PNL,50 OHM,FEMALE,STR,
PELTOLA/PNL MNT,SILVER ALLOY, 0.576 MLG X 0.366
TERMN,0.375-32 THD,D-FLAT
2 CABLE ASSY ELEC: RF,COAX,22.8IN L,50 OHM,
PELTOLA,PELTOLA,FLEX COAX CABLE
1 CABLE ASSY ELEC: RF,COAX,9.5IN L,50 OHM,SMA-R STR
PANEL,SMP-R RTA, W/LABEL,MATCHED DELAY FLEX
COAX CABLE
2 CABLE ASSY ELEC: RF,COAX,9.5IN L,50 OHM,SMA-R STR
PANEL,SMP-R RTA, W/LABEL,MATCHED DELAY FLEX
COAX CABLE
2 CABLE ASSY ELEC: RF,COAX,7IN L,50 OHM,SMP-R RTA,
SMA-R STR, PANEL MOUNT, W/LABEL,MATCHED DELAY
FLEX COAX CABLE
4 CABLE ASSY ELEC: RF,COAX,7IN L,50 OHM,SMP-R RTA,
SMA-R STR, PANEL MOUNT, W/LABEL,MATCHED DELAY
FLEX COAX CABLE
1 CABLE ASSY ELEC: RF,COAX,13.8IN L,50 OHM,SMA-P
STR, SMA-R STR, PANEL MOUNT,W/LABEL,MATCHED
DELAY FLEX COAX CABLE
3 CABLE ASSY ELEC: RF,COAX,13.8IN L,50 OHM,SMA-P
STR, SMA-R STR, PANEL MOUNT,W/LABEL,MATCHED
DELAY FLEX COAX CABLE
Replaceable Parts
5–37
