Table 4-7: Calibration error codes (cont.)
Error code Error log message
261000200 Waveform write error
261001001
Invalid NG Areas. (ch1_ram_address_timing@12GHz)
261001002 Invalid NG Areas. (ch2_ram_address_timing@12GHz)
261001003 Invalid NG Areas. (ch1_ram_address_timing@10GHz)
261001004
Invalid NG Areas. (ch2_ram_address_timing@10GHz)
262000011 The Cal value is not found. (ch1_pld_timing_1@12GHz)
262000012 The Cal value is not found. (ch2_pld_timing_1@12GHz)
262000013 The Cal value is not found. (ch1_pld_timing_2@10GHz)
262000014 The Cal value is not found. (ch2_pld_timing_2@10GHz)
262000015
The Cal value is not found. (ch1_pld_timing_3@12GHz)
262000016 The Cal value is not found. (ch2_pld_timing_3@12GHz)
262000017 Temperature changed 5 degrees or more.(@PLD
Timing Cal.)
262000111
The difference of ch1_pld_timing_1 and
ch2_pld_timing_1 is larger than 24.(@12GHz)
262000113 The difference of ch1_pld_timing_2 and
ch2_pld_timing_2 is larger than 24.(@10GHz)
262000115 The difference of ch1_pld_timing_3 and
ch2_pld_timing_3 is larger than 24.(@12GHz)
262001005 Invalid NG Areas. (ch1_pld_timing@12GHz)
262001006 Invalid NG Areas. (ch2_pld_timing@12GHz)
262001007 Invalid NG Areas. (ch1_pld_timing@10GHz)
262001008 Invalid NG Areas. (ch2_pld_timing@10GHz)
263000025 tek15_ch1_k is not 6, 7 or 8.
263000026 tek15_ch2_k is not 6, 7 or 8.
263000027
The Cal value is not found. (tek15_ch1_ng_f)
263000028 The Cal value is not found. (tek15_ch2_ng_f)
263000029 Temperature changes 5 degrees or more during
MagicCal.
263000031 Set end point before start point. Or too large delay was
set as reference delay (CH1).
263000032 Set end point before start point. Or too large delay was
set as reference delay (CH2).
263000125 tek15_ch1_k and tek15_ch2_k are not equal.
263001106 Temperature changes 5 degrees or more from PLD
timing Cal.
AWG7000B and AWG7000C Series Service Manual
Possible defect
on board Note
AWG12G AWG12G:U1000, U400A/B,
U500A/B, U510A/B
AWG12G
AWG12G
AWG12G
AWG12G
AWG12G AWG12G:U300A, U400A
AWG12G AWG12G:U300B, U400B
AWG12G AWG12G:U300A, U400A
AWG12G AWG12G:U300B, U400B
AWG12G AWG12G:U300A, U400A
AWG12G AWG12G:U300B, U400B
AWG12G Ambient temperature
AWG12G AWG12G:U300A/B, U400A/B
AWG12G AWG12G:U300A/B, U400A/B
AWG12G AWG12G:U300A/B, U400A/B
AWG12G AWG12G:U300A,U400A
AWG12G AWG12G:U300B,U400B
AWG12G AWG12G:U300A,U400A
AWG12G AWG12G:U300B,U400B
AWG12G AWG12G:U100A, U300A
AWG12G AWG12G:U100B, U300B
AWG12G AWG12G:U100A, U300A
AWG12G AWG12G:U100B, U300B
AWG12G Ambient temperature
AWG12G AWG12G:U100A,U300A
AWG12G AWG12G:U100B, U300B
AWG12G AWG12G:U100A/B,U300A/B
AWG12G Ambient temperature
Troubleshooting
4–69
