Replaceable Parts
Table 5-7: Replaceable parts list – AWG7000C Series drive modules
Fig. & index Tektronix
number part number
5-7-
-1 407-5156-00
-2 211-1050-00
-3 211-0950-00
-4 119-7473-00
-5 174-5650-00
-6 441-2474-03
-7 211-1050-00
-8 174-5349-00
-9 407-5337-00
-10 211-1050-00
-11 650-5336-00
-12 351-1118-00
-13 211-1174-00
-14 407-5331-00
-15 211-0734-00
5–12
Serial no. Serial no.
effective dis-cont'd Qty Name & description
DRIVE MODULE
1 BRACKET,DVD-CD/RW;ADAPTER FOR DVD-CD/RW SLIMLINE
2 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
4 SCREW,MACHINE; M2X.4X3L,PHL, PNH, STL NI PL
1 DISK DRIVE; OPTICAL, CD-RW/DVD ROM OR COMBO, SATA,
DW224SV93;SAFETY CONTROLLED
1
CABLE, SATA-DVD, DATA AND POWER, SAFETY CONTROLLED
1 CHASSIS;DRIVE BAY;METAL
7 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 CABLE ASSY; SATA COMBO, HARD DRIVE CABLE WITH LATCH
1 BRACKET,RHDD; SATA COMBO CABLE RETENTION
2 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 ACCESSORY KIT; REMOVABLE HARD DRIVE ASSEMBLY, V4.0
PROGRAMMED FW
1 GUIDE,HD; REMOVABLE,3.5 INCH HARD DISK DRIVE, SAFETY
CONTROLLED
4 SCREW,MACHINE; W/HEAVY PATCH THREADLOCKING MATERIAL;
6-32 X 0.312 L,PNH,STL CAD PLT,T15
1 BRACKET, ASSEMBLY, REMOVABLE 3.5 INCH HARD DRIVE
CARTRIDGE
4 SCREW,MACHINE; 6-32 X 0.250,FLH100,STL,CDPL,T-10 TORX DR
