I Auto Repeater - Icom IC-207H Instruction Manual

I Auto repeater

(U.S.A. version only)
The U.S.A. version automatically activates the repeater set-
tings (DUP or DUP– and tone encoder ON/OFF) when the
operating frequency falls within the general repeater output
frequency range and deactivates them when outside of the
range.
D Setting the auto repeater function ON/OFF
➀
Push [PWR] to turn power OFF.
➁
While pushing [SET] (far right switch), turn power ON to
enter initial set mode.
➂
Push [SET] one or more times until the "rPt" display ap-
pears as shown below.
Auto repeater function is
turned OFF
➃
Rotate the tuning dial to turn the auto repeater function to
"r1," "r2" or OFF.
• "r1": auto repeater is ON, tone encoder is OFF;
"r2": auto repeater is ON, tone encoder is ON.
➄
Push [PWR] momentarily to exit initial set mode.
INITIAL SET MODE
USING
DUP T
Auto repeater function is ON,
tone encoder is OFF.
REPEATER OPERATION
D Frequency range and offset direction
FREQUENCY RANGE
145.200–145.495 MHz
146.610–146.995 MHz
147.000–147.395 MHz
442.000–444.995 MHz
447.000–449.995 MHz
5
DUPLEX DIRECTION
"DUP–" appears
"DUP" appears
"DUP" appears
"DUP–" appears
28
