DTMF MEMORY ENCODER

I DTMF speed

The rate at which DTMF memories send individual DTMF
characters can be set to accommodate operating needs.
➀
Push [PWR] to turn power OFF.
➁
While pushing [SET] (far right switch), push [PWR] for 1
sec. to turn power ON and enter initial set mode.
➂
Push [SET] or [MONI] to select the "dtd" display as shown
above.
➃
Rotate the tuning dial to select the desired speed as shown
in the table below.
➄
Push [PWR] momentarily to exit initial set mode.
DISPLAY INTERVAL
dtd-1 100 msec.
dtd-2 200 msec.
dtd-3 300 msec.
dtd-5 500 msec.
49
INITIAL SET MODE
USING
The display shows the fastest
DTMF speed is selected.
SPEED
5.0 cps
2.5 cps
1.6 cps
cps=
1.0 cps
characters/second
