DO NOT
allow children to play with any radio equipment
containing a transmitter.
DO NOT
During mobile operation,
without running the vehicle's engine. When transceiver power
is ON and your vehicle's engine is OFF, the vehicle's battery
will soon become exhausted.
BE CAREFUL!
The transceiver will become hot when
operating it continuously for long periods.
AVOID
using or placing the transceiver in areas with tem-
peratures below –10°C (+14°F) or above +60°C (+140°F) or
in areas subject to direct sunlight, such as the dashboard.
AVOID
the use of chemical agents such as benzine or alcohol
when cleaning, as they can damage the transceiver surfaces.
USE
Icom microphones only (supplied or optional). Other
manufacturer's microphones have different pin assignments
and may damage the transceiver if attached.
Note that in this manual, sections beginning with a
microphone icon (as at left) designate operation via
the HM-98 microphone.
operate the transceiver

UNPACKING

➀ ➁
➉
➆
➄
Accessories included with the transceiver:
➀
DC power cable (OPC-346)............................................. 1
➁
Mobile mounting bracket ................................................. 1
➂
Microphone (HM-98*) ...................................................... 1
➃
Fuse (20 A)...................................................................... 1
➄
Knob bolt (M4 × 8) ........................................................... 4
➅
Mounting bolt (M5 × 12)................................................... 4
➆
Nut (M5)........................................................................... 4
➇
Spring washer (M5) ......................................................... 4
➈
Flat washer (M5).............................................................. 4
➉
Self-tapping screws (A0 5 × 16)....................................... 4
*Some versions are supplied with the HM-96 instead.
➂
➃
➅
➇
➈
Qty.
