The Boot Console Interface

Changing the Console to External Terminal

Changing the Console to External Terminal
In the event that your console stops displaying to your graphics device,
use the following procedure to display the console to an external serial
terminal so that you can configure the graphics console:
1. Turn the system's power off.
2. Disconnect the USB keyboard connector from the system rear panel.
3. Connect a serial terminal to the serial connector 1 on the system rear
panel. The serial parameters are: 9600 baud, 8 data bits, no stop bits.
4. Power on the system.
The system will now display the console to the terminal connected to
Serial 1 port.
Chapter 8 153
