4
RECEIVING AND TRANSMITTING
Operating CW (Continued)

D Setting the key speed

You can set the key speed of the internal electric
keyer.
1. Select the CW mode.
2. Display the Multi-function menu.
3. Touch [KEY SPEED].
4. Set the key speed to between 6 and 48 Words Per
Minute (WPM).

D About the Break-in function

Use the Break-in function in the CW mode to
automatically switch between transmit and receive
when keying. The IC-7300 is capable of Semi Break-in
and Full break-in modes.
TIP: The key type is set to "Paddle" by default. You can
select the keyer type on the CW-KEY SET screen.
Push
(p. 4-21)
Semi Break-in mode
In the Semi Break-in mode, the transceiver transmits
when keying, and then automatically returns to receive
after a preset time after you stop keying.
1. Select the CW mode.
2. Push
L Pushing
"F-BKIN (Full Break-in)" or OFF (no indication).
Semi Break-in
Rotate
3. To adjust the Break-in delay time, hold down
Push
VOX/BK-IN
• Opens the BKIN menu.
4. Set to where the transceiver does not return to
receive while keying.
L When you are using a paddle, push
the Multi-function menu, and then adjust the KEY
SPEED while operating the paddle.
5. To close the BKIN menu, push
4-15
to display "BKIN."
VOX/BK-IN
VOX/BK-IN selects "BKIN (Semi Break-in),"
for 1 second.
Rotate
to display
MULTI
.
EXIT
