ABOUT THE INSTRUCTIONS
The Full and Basic manuals are described based on
the following:
" " (Quotation marks):
Used to indicate icons, setting items, and screen titles
displayed on the screen.
The screen titles are also indicated in uppercase letters.
(Example: FUNCTION screen)
[ ] (brackets):
Used to indicate keys.
Routes to the set modes and setting screens
Routes to the set mode, setting screen and the setting
items are shown in the following manner.
» SET > Display > Display Type
MENU
Instruction example
Detailed instruction
1. Push .
MENU
Push
• Opens the MENU screen.
2. Touch [SET].
MENU screen
• Opens the SET screen.
3. Rotate , and then push
MULTI
"Display."
SET screen
4. Rotate , and then push
MULTI
"Display Type."
DISPLAY screen
"Display Type" screen
v
to select
MULTI
Rotate
Push
to select
MULTI
Rotate
Push
