19
CONTROL COMMAND
Remote control (CI-V) information (Continued)
• Band stacking register
Command: 1A 01
q
X X
q Frequency band codes
Code Freq. band Frequency range (unit: MHz)
01 1.8
02 3.5
03 7
04 10
05 14
06 18
07 21
08 24
09 28
10 50
11 GENE
w Register codes
Code Registered number
01 1 (latest)
02 2
03 3 (oldest)
For example, when sending/reading the oldest
contents in the 21 MHz band, the code "0703" is used.
• Offset frequency settings
Command : 1A 050031, 050032
q w
X 0 X X
*1 There is no need to enter the transverter offset frequency setting.
*2 Transverter offset only. Fix to '0' for split offset setting.
w
X X
1.800000–1.999999
3.400000–4.099999
6.900000–7.499999
9.900000–10.499999
13.900000–14.499999
17.900000–18.499999
20.900000–21.499999
24.400000–25.099999
28.000000–29.999999
50.000000–54.000000
Other than above
e r*
0 X XX
• Codes for character entries
- Character codes— Letters and Numbers
Character ASCII code
A–Z 41–5A
0–9 30–39
- Character codes— Symbols
Character ASCII code
!
$
&
?
'
^
−
/
,
;
<
(
[
{
|
͂
Command Set item/selectable characters
1A 00 Memory name
All characters are usable.
1A 050091 Opening message
Uppercase letters, numbers, symbols
(− / . @) and space are usable.
• Data mode with filter width settings
Command : 1A 06
00=Data mode OFF*
01=Data mode ON
*
When 00 is set, also set 00 to w
19-9
Character ASCII code
a-z 61–7A
Character ASCII code
21 #
24 %
26 \
3F "
27 `
5E +
2D
✱
2F .
2C :
3B =
3C >
28 )
5B ]
7B }
7C _
7E @
q w
X X X X
01=FIL1
02=FIL2
03=FIL3
23
25
5C
22
60
2B
2A
2E
3A
3D
3E
29
5D
7D
5F
40
