RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots
Ethernet Port
Antenna Port
Personality Module
Weight
Environmental
Operating Temperature
Humidity
External Power
PoE Injector
Peak Power Consumption
Agency Approvals & Certifications
Visit www.prosoft-technology.com
ProSoft Technology, Inc.
(1) 10/100 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x
Water/Dust Tight M12 Connector (RLX2-IHNF-W)
10/100/1000 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x, 802.3af, Passive PoE
Not 802.3at/PoE+ compatible
Water/Dust Tight (RLX2-IHNF-WC)
10/100/1000 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x, 802.3af
(3) RP-SMA connector
(3) N-Type Connectors (RLX2-IHNF-W and WC)
Industrial SD Memory Module
No Personality Module on RLX2-IHNF-W or WC
1.1 lbs (499 g) (RLX2-IHNF)
3 lb 9 oz, 1.6 Kg – less cables and pole mounting bracket (RLX2-
IHNF-W or WC)
-40°F to +167°F (-40°C to +75°C)
-40°F to +158°F (-40°C to +70°C), RLX2-IHNF Series B and C only
Up to 100% RH, with no condensation
10 to 24 VDC
802.3af PoE Powered Device
The RLX2-IHNF-WC has a 6-foot attached cable and a 6-foot
attached CAT6 cable for PoE applications
< 9W (Series B), < 8W (Series C)
for current wireless approval information.
Appendix J - Detailed Radio Specifications
