Parameter
MAC
IP
Mode
SSID
TX Rate
RX Rate
Master
Signal
More / Less
Mask
Gateway
Connection
Software Version
Boot Version
Compression
Associations
Bridges
Hop Count
Channel
Ethernet
Security
Missed Responses
ProSoft Technology, Inc.
Description
Displays the MAC address of the selected radio.
Displays the IP address of the selected radio.
Displays the mode of the selected radio (M
B C )
RIDGING LIENT
Displays the SSID of the selected radio.
Displays a green bar when there is transmit activity.
Displays a green bar when there is receive activity.
Displays the MAC address of the radio's current Master radio.
Displays a green bar when there is a signal.
Click M to expand the dialog box and display more information.
ORE
Click L to reduce the dialog box and display less information.
ESS
Displays the network mask for the current radio.
Displays the network gateway IP for the current radio.
Displays the connection state for a Repeater radio.
S - The radio is searching for a Master radio.
CANNING
C - The radio is linked to a Master radio.
ONNECTED
Displays the version of the firmware code in the radio. This is not the
version of the image file installed into the radio (for that information see
I described below).
MAGE
Displays the boot loader code version number. This is the version of the
boot loader code in the radio.
Displays the type of the firmware image that the radio is currently
running (P or S
RIMARY ECONDARY
operating firmware installed, and the radio will automatically switch from
one to the other if one of them becomes corrupted.
Displays the compression state of the firmware images in the radio
(C or U
OMPRESSED NCOMPRESSED
Displays the number of non-bridge wireless connections to this radio.
Client or Bridging Client radios that are connected always show 1 in this
column (and 0 in the Bridges column).
Displays the number of non-bridge wireless connections to this radio.
Client or Bridging Client radios that are connected always show 1 in this
column (and 0 in the Bridges column).
Displays the number of wireless connections from the device to the
wired connection of a Master. This value is always 1 for a Master radio.
For Repeater radios, the value is at least 2, but can be higher if there
are more hops to the Master radio. Client radio do not display a hop
value.
Displays the operating channel for radio.
Displays the Ethernet status for the radio.
A - The radio is connected to a wired Ethernet network.
TTACHED
D - The radio is not connected to a wired Ethernet network.
ETACHED
Displays the encryption type setting for the radio. Some valid settings
are AES, TKIP, AES&TKIP, WEP128 TKIP, WEP128, WEP64.
Displays the number of times the IH Browser has failed to receive a
response from the device after a scan. Ideally this number should
always be zero.
Using the IH Browser to Manage your Radios
