16 Appendix J - Detailed Radio Specifications

16.1 RLX2-IHA Detailed Specifications

RLX2-IHA Radio
Frequency Band
(Varies by country)
Wireless Standards
Transmit Power (Programmable)
(varies by country)
Channel Data Rates (Modulation)
Receiver Sensitivity (Typical)
Channel Selection
Security
Physical
Enclosure
Size
(H x W x D)
Shock
Vibration
Ethernet Ports
Serial Port
Antenna Port
Weight
Environmental
Operating Temperature
Humidity
External Power
Power over Ethernet
Peak Power Consumption
Agency Approvals & Certifications
Visit www.prosoft-technology.com
ProSoft Technology, Inc.
802.11a
5.150 GHz to 5.250 GHz (FCC/ETSI)
5.725 GHz to 5.850 GHz (FCC)
802.11a, 802.11i
23 dBm (200 mW)
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
-92 dBm @ 6 Mbps
-84 dBm @ 24 Mbps
-72 dBm @ 54 Mbps
36, 40, 44, 48, 149, 153, 157, 161, 165
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter, Admin password
Extruded aluminum with DIN and panel mount
14.8 x 11.8 x 3.8 cm
5.82 x 4.64 x 1.48 in
IEC 60068 2-27 (20g, 3-Axis)
IEC 60068 2-6 (5g, 10Hz to 150Hz)
(1) 10/100/1000 Base-T, RJ45 connector
(1) DB9 female (serial tunneling & encapsulation)
(1) RP-SMA connector
1.1 lbs (499g)
-40°C to +75°C (-40°F to +167°F)
Up to 100% RH, with no condensation
10 VDC to 24 VDC
802.3af Compliant
< 7W
for current wireless approval information.
