RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots

13.3.3 Approved Antennas in Mexico

The gain of the antenna connected to the RLX2-IHx series radio main antenna port,
minus the antenna cable loss, must be less than 12 dB to stay below the 650-mW EIRP
transmit power limit.
Note: In Mexico, the user is responsible for ensuring that the selected frequency channels comply with
Mexican regulatory standards. At the time of this printing, only channels 9 through 11 can be used outdoors
(1 through 8 cannot); however, channels 1 through 11 can all be used indoors.

13.3.4 Approved Antennas with Power Amp

When the RLX2-IHx series radio is used in conjunction with the amplifier, the antennas
are limited to antennas listed in the following table.
Type
1/2 Wave
1/2 Wave art.
Collinear Array
Collinear Array, art. Omni
Collinear Array
Collinear Array
Collinear Array
Collinear Array*
Patch
Patch*
Patch*
Yagi*
* Only allowed in a point-to-point network.
ProSoft Technology, Inc.
Pattern Gain Connector
Omni 2 dB SMA-RP
Omni 2 dB SMA-RP
Omni 3 dB SMA-RP
5 dB SMA-RP
Omni 5 dB SMA-RP
Omni 8 dB N-RP
Omni 9 dB N-RP
Omni 12 dB N-RP
Directional 8 dB SMA-RP
Directional 11 dB SMA-RP
Directional 13 dB N-RP
Directional 14 dB N-RP
Appendix G - Antenna Configuration
Size (cm) Min. distance from
Body
20 cm
7H x 1.5
10H x 1.0 20 cm
6H x 3.0 20 cm
19H x 1.0 20 cm
19H x 1.0 20 cm
20 cm
43H x 1.6
43H x 1.6 20 cm
106H x 4.0 25 cm
15.0H x 15.0 20 cm
22H x 12.7 20 cm
22H x 22 28 cm
81L x 9.0 28 cm
User Manual
Page 226 of 248
