ProSoft Technology RLX2-IHW-E User Manual page 161

RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots
Auto Compare View
The Auto Compare view compares the settings of the displayed units by grouping them
and highlighting the differences. Repeaters are only compared against other Repeaters,
and Masters against other Masters.
The largest group of Repeaters and the largest group of Masters with common settings
becomes the Reference. The differences between the Repeaters/Masters and their
respective References are displayed.
The example below shows that all units have the same settings. All Repeaters are a part
of the Reference Repeater group and all Masters are a part of the Master Reference
group.
You can browse the settings by expanding (+) the Reference xxx Settings groups.
ProSoft Technology, Inc.
Using the IH Browser to Manage your Radios
User Manual
Page 161 of 248
