7.3.2 RLX2.STATUS

This array is populated when the RLX2.CONTROL.Get_Status_Data is triggered. The
following is the CIP™ object definition to read the RLX2-IHx Diagnostics and Status
information.
CIP Data Tag Name
RLX2.STATUS.SSID
RLX2.STATUS.IPAddress
RLX2.STATUS.MACAddress
RLX2.STATUS.NetworkMode
RLX2.STATUS.ConnectionState
RLX2.STATUS.SignalStrength
RLX2.STATUS.Channel
RLX2.STATUS.WEP
RLX2.STATUS.Flags
RLX2.STATUS.MasterMACAddress
RLX2.STATUS.HopCount
RLX2.STATUS.PortStatus
RLX2.STATUS.Associations
RLX2.STATUS.BridgeAssociations
RLX2.STATUS.TxRadioThroughput
ProSoft Technology, Inc.
Data Type Description
SINT[32] Service Set Identifier is a name assigned to the
wireless network
SINT[4] IP address of RLX2-IHx radio
SINT[6] Media Access Control (MAC) address of the device
SINT RLX2 radio network mode
6 = Master
7 = Repeater
1 = Client
SINT Connection State of RLX2 radio found at the bit-
level (RLX2.STATUS.ConnectionState.x)
Bit sequence [yyyy 0001] = 1 = Not connected
Bit sequence [yyyy 0010] = 2 = Scanning
Not reported
Bit sequence [yyyy 0100] = 4 = Globally connected
Where y = RLX2 radio model type:
Bit sequence [0001 zzzz] = 802.11g (2.4 GHz) radio
Bit sequence [0010 zzzz] = 802.11a (5 GHz) radio
Bit sequence [0011 zzzz] = 802.11n radio
Example:
Bit sequence 0010 0100 = 36 = Globally connected
5 Ghz radio
INT Current Strength of the signal in dBm
Current Channel in which RLX2-IHx is transmitting
SINT
WEP encryption key
SINT
DINT Flags value when bit is set:
Flags [0/1 ] = Extension channel above/below
Flags [2] = SSID is hidden
Flags [3] = Do not allow children
Flags [4/5] = STP/RSTP enabled
Flags [6] = Transmit using GI40
Flags [7] = (Not used)
Flags [8] = RLX2-IHx in Bridging Client Mode
Flags [9] = DHCP is enabled
Flags[10] = NAT is enabled
SINT[6] MAC Address of Parent Radio in which Repeater or
Client is linked
SINT Number of hops to the master
SINT Ethernet Port Status
xxxx x1xx = RLX2-IHx Ethernet cable attached
x, N/A
INT Number of devices wirelessly connected to radio
INT Number of RLX2-IHx bridges to which radio has a
wireless connection
INT If bit 15 = 0, then bits 0 to 14 represent the
throughput in kilobits/sec.
