ProSoft Technology RLX2-IHW-E User Manual page 210

RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots
RLX2_Diag.rx_good
RLX2_Diag.tx_bad
RLX2_Diag.rx_bad
RLX2_Diag.tx_directed_frames
RLX2_Diag.tx_multicast_frames
RLX2_Diag.tx_broadcast_frames
RLX2_Diag.rx_directed_frames
RLX2_Diag.rx_multicast_frames
RLX2_Diag.rx_broadcast_frames
RLX2_Diag.rx_crc_error
The following registers are available if the firmware in the RLX2 is
RLX2_v0038_R or greater.
RLX2_Diag.Retries
RLX2_Diag.Utilization
RLX2_Diag.ChannelWidth
RLX2_Diag.NumAntennas
RLX2_Diag.TxRate
RLX2_Diag.TxBitRate
RLX2_Diag.TxBcstRate
RLX2_Diag.TxMcstRate
RLX2_Diag.OS_Files
RLX2_Diag.Wireless_Files
RLX2_Diag.Config_Files
RLX2_Diag.Security_Files
RLX2_Diag.Web_Files
RLX2_Diag.SD_Card_Files
*Modbus Function Code 4 (Read Input Registers(3X)) is supported.
ProSoft Technology, Inc.
Appendix E - EtherNet/IP and Modbus TCP/IP Support
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
INT Read
INT Read
INT Read
INT Read
INT Read
INT Read
INT Read
INT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
DINT Read
30094 to 30095
30096 to 30097
30098 to 30099
30100 to 30101
30102 to 30103
30104 to 30105
30106 to 30107
30108 to 30109
30110 to 30111
30112 to 30113
30114
30115
30116
30117
30118
30119
30120
30121
30122 to 30123
30124 to 30125
30126 to 30127
30128 to 30129
30130 to 30131
30132 to 30133
